Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board

Certification
China Shenzhen XH Technology Co., Ltd. certification
I'm Online Chat Now

Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board

Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board
Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board

Large Image :  Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board

Product Details:
Place of Origin: China, Shenzhen
Brand Name: XH
Certification: ISO FCC
Model Number: XH00
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Price: 2.835USD per KG
Packaging Details: 1500kg/Tray
Delivery Time: 7 working days
Payment Terms: T/T, Western Union
Supply Ability: 500000kg/per Month

Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board

Description
Size: 1220*2440mm, 1220*1830, 2050*3050, 1220*2440mm And So On, Custom Size Density: 1.2g/cm3,
Color: Transparent Raw Material:: 100% Virgin Lucite Mma
Customized: Size And Colour Customized Place Of Origin: Shenzhen
High Light:

Extruded Plexiglass Acrylic Sheet

,

Lucite Plexiglass Acrylic Sheet

,

3mm Lucite Board

Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board



transparent plexiglass acrylic sheet 3mm thin large roofing extruded lucite board cut to size


 1.  Product Description
      The acrylic sheet has crystal-like transparency, the light transmittance is more than 92%, and the acrylic sheet colored with dye has a good color development effect. In addition, the acrylic sheet has excellent weather resistance, high surface hardness and surface gloss and good high temperature resistance. Acrylic sheet has good processing performance, and can be divided into casting type and extrusion type according to the production process. Both thermoforming (including molding, blow molding and vacuum forming) can be used, and mechanical processing methods such as drilling, turning, milling, cutting, etc. can be used. The mechanical cutting and engraving controlled by microcomputer not only greatly improves the processing accuracy, but also can produce more exquisite patterns and shapes than traditional methods. In addition, acrylic sheets can be laser-cut and laser-engraved to make products with peculiar effects.
Hardness is one of the parameters that best reflects the production process and technology of cast acrylic sheets, and is an important part of quality control. The hardness can reflect the purity of the raw material MMA, the weather resistance and the high temperature resistance of the plate. The hardness directly affects whether the plate will shrink and bend, and whether the surface will crack during processing. Hardness is one of the hard indicators for judging the quality of acrylic sheets. The cast acrylic sheet has the highest hardness index and an average Rockwell hardness value of 90 degrees.



2. Parameter

Extruded Clear Transparent Acrylic Plexiglasss sheet Parameter
Item Place of Origin Guangdong China
Brand Name XH (Acrylic sheet manufacturer)
Model Number H-00
Material High quality Virgin MMA raw material
Specification Thickness 0.8mm-20mm
Acrylic sheet Size 2440x1220mm, 1220*1830mm, customized
Density 1.2g/cm3
Appearance Color Clear / Black / White / Blue / Red or customized
Light Transmission >92.8%
Surface Double Polished
Process Available Processing Type Extruded
Process Service Custom Cut to Size,laser dot,UV printing
Sample Sample fee Normal A4 size is free, just shipping fee
Sample Time Normal size, 2days
Customized sample Fee and time will be discussed by both
Supply Capacity Production Ability 50000 Pieces per Month
Stock Regular size stock is sufficient
Lead time 7-10 days after your order
Package Acrylic sheet Covered by PE film or craft paper on double sides
Package Wooden pallet
Package size 2450mm*1250mm*700mm or customized
Package weight About 2000kg per pallet or customized


Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board 0


3.  Plexiglasss sheet Advantage

1. Hardness: Hardness is one of the parameters that best reflects the production process and technology of cast acrylic sheets, and is an important part of quality control. The hardness can reflect the purity of the raw material MMA, the weather resistance and the high temperature resistance of the plate. The hardness directly affects whether the plate will shrink and bend, and whether the surface will crack during processing. Hardness is one of the hard indicators for judging the quality of acrylic sheets. The imported cast acrylic sheet has the highest hardness index of the same domestic product. The average Da Rockwell hardness value is about 89 degrees.
2. Thickness tolerance: The thickness tolerance here is the thickness tolerance of the acrylic sheet. The control of this tolerance is an important manifestation of quality management and production technology. The thickness tolerance of imported cast acrylic sheet is controlled within +0.2mm.
3. Transparency/whiteness: Strict raw material selection, advanced formula follow-up and modern production technology ensure excellent transparency and pure whiteness of the board. Crystal clear after flame polishing.


4.   Transparent Acrylic sheet Application

     The name of acrylic is methyl methacrylate. It is the best and easiest thermoplastic material in plastics. Its various finished product specifications are widely used in color light cover, lighting ceiling, aircraft and vehicle door and window glass, door and window cover, windscreen, Mechanical covers, daily necessities, decoration, advertising materials, handicrafts, crystal furniture, shower utensils, kitchen utensils, etc.
1. Architectural applications: shop windows, soundproof doors and windows, lighting covers, telephone booths, etc.
2. Advertising applications: light boxes, signs, signs, display stands, etc.
3. Transportation applications: doors and windows of vehicles such as trains, cars, etc.
4. Medical applications: baby incubators, various surgical medical appliances, civilian products: sanitary facilities, handicrafts, cosmetics, brackets, aquariums, etc.
5. Industrial application: instrument panel and cover, etc.
6. Lighting applications: fluorescent lamps, chandeliers, street lampshades, etc.

Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board 1

5.  XH Company and Production Line

Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board 2



7.  Package and shipping



7.1. One piece of acrylic sheet package: double-sided covered with kraft paper or PE film, the cover film does not have any LOGO of our company.

7.2. Tray package: the total weight of each pallet is about 2 tons, the bottom is wooden pallet or iron pallet, and the surrounding is packed with corrugated paper.

7.3. The packaging method of the whole container: 20-23 tons (about 3000 pieces) 20-foot container, 10-12 pallets.

Transparent Plexiglass Acrylic Sheet Roofing Extruded Lucite Board 3
