2mm Translucent Green Coloured Acrylic Sheet Extruded Perspex Plate

Certification
China Shenzhen XH Technology Co., Ltd. certification
I'm Online Chat Now

2mm Translucent Green Coloured Acrylic Sheet Extruded Perspex Plate

2mm Translucent Green Coloured Acrylic Sheet Extruded Perspex Plate
2mm Translucent Green Coloured Acrylic Sheet Extruded Perspex Plate 2mm Translucent Green Coloured Acrylic Sheet Extruded Perspex Plate 2mm Translucent Green Coloured Acrylic Sheet Extruded Perspex Plate

Large Image :  2mm Translucent Green Coloured Acrylic Sheet Extruded Perspex Plate

Product Details:
Place of Origin: China, Shenzhen
Brand Name: XH
Certification: ISO FCC
Model Number: XH 362
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Price: 2.835USD per KG
Packaging Details: 1500kg/Tray
Delivery Time: 7 working days
Payment Terms: T/T, Western Union
Supply Ability: 50000kg/per Month

2mm Translucent Green Coloured Acrylic Sheet Extruded Perspex Plate

Description
Material: Acrylic, 100% Virgin Lucite MMA Density: 1.2g/cm3,
Color: Translucent Green Specification: 1220 X 1830, 1220 X 2440,
Transport Package: Film+pallet; Kraft Paper+pallet Product Name: Colour Plexiglass Sheets
Application: Signs, Displays, Doors, Furniture, Gift Articles, Etc.
High Light:

2mm Coloured Acrylic Sheet

,

Extruded Coloured Acrylic Sheet

,

Perspex Translucent Acrylic Sheet

2mm Translucent Green Coloured Acrylic Sheet extruded perspex plate


1.  Description of
Translucent Green Acrylic Sheet

     The extruded sheet has lower molecular weight, slightly weaker mechanical properties and higher flexibility, which is beneficial to bending and thermoforming, and has a shorter softening time. At the same time, the thickness tolerance of the extruded sheet is smaller than that of the cast sheet. Due to the large-scale automatic production of extruded sheets, the diversity of product colors and specifications is limited to a certain extent.



2.  Parameter of Translucent Green Acrylic Sheet

PROPERTIES VALUES RULES
Density 1.19 g/cm3 ISO 1183-1:2012 Method A
Rockwell Hardness 112L ISO 2039-2:1999
Tensile Modulus 3150MPa EN ISO 527:2012
Tensile Strength 80.0MPa EN ISO 527:2012
Tensile Strain at Break 3.2% EN ISO 527-1:2012
Water Absorption 0.20% ISO 62:2008 Method 1
Total Luminous Transmittance 93.4% ISO 13468-1:1996
Vicat Softening Temperature 105℃ ISO 306:2013 Method B50
Light Ageing Test- UV Exposure Grey scale: 5 ISO 4892-3:2016 Cycle 1
Mean Coefficient of Linear Thermal Expansion 72×10-6 K-1 ISO 11359-1:2014
Compressive Stress at Yield 129MPa EN ISO 604:2003
Flexural Strength 120MPa ISO 178:2013
Compressive Yield Strength 111MPa ASTM D695-15
Compressive Modulus 3450MPa ASTM D695-15
Shear Strength 59.7MPa ASTM D732-17
Deflection Temperature under Load 100.2℃ ASTM D648-18 Method B
Modulus Elasticity 2810MPa ASTM D695-15



2mm Translucent Green Coloured Acrylic Sheet Extruded Perspex Plate 0





3.  Translucent Green Acrylic Sheet Types

Transparent, light red, red, yellow, orange, black transparent, brown, black tea, light blue, blue, dark blue, smoke grey, tea grey, grey, grey tea, dark tea, smoke grey tea, yellow grey tea, Ink brown, light yellow tea, light green, pink, glass blue, glass blue, light purple, purple.



4.Translucent Green Acrylic Sheet Application

(1).  Showcases, soundproof doors and windows, lighting covers, chandeliers, bathroom facilities,  screens, etc.
(2).  Advertising light boxes, signs, signs, display stands, etc.
(3).  trains, cars, taxis and other vehicles doors and windows, etc.
(4).  Baby incubators, various surgical medical equipment, etc.
(5).  Instrument panel, cover, etc.
